| Place Of Origin: | Shenzhen, China | Certification: | ISO9001, ISO14001, ISO13485, and IATF16949. |
| Surface Finish: | 0.8-2.0 Mm | Operating Temperature: | -40°C - 85°C |
| Number Of Layers: | From 2 - Up To 48 Layers | Certifications: | IPC, RoHS, UL, ISO9001, ISO14001,ISO13485,IATF16949 |
| Testing And Inspection: | Automated Optical Inspection (AOI), X-ray Inspection | Assembly Accuracy: | Tolerance Within ±0.05 - 0.1mm For Component Placement |
| Other Service: | We Can Help With The Procurement Of Electronic Components On Behalf Of Customers. | Cost Efficiency: | Competitive Pricing And Cost Reduction Strategies |
| Environmental Responsibility: | Sustainable Practices And Green Initiatives | Customization: | Tailored Solutions To Meet Customer's Specific Requirements |
| Manufacturing Capabilities: | PCB Assembly, Box Build Assembly, Cable And Wire Harness Assembly, Testing And Inspection | Quick Turnaround Time: | Rapid Prototyping And Fast Production Lead Times |
| Flexibility: | Ability To Handle Small To Large Production Volumes | Packaging Details: | Vacuum packing+Cardboard packing case |
| Supply Ability: | 50000㎡per week | ||
| Highlight: | 10 layer multilayer PCB fabrication, custom multilayer PCB manufacturing, PCB assembly solution with warranty | ||
- This product showcases a customized 10-layer multilayer printed circuit board manufactured by Ring PCB for a client requiring high-density, high-speed, and reliable electronic performance.
- With fine line spacing (3mil/3mil), precise layer alignment, and a compact layout, this multilayer PCB is designed for applications where signal integrity, thermal stability, and space optimization are critical.
- Ring PCB provides end-to-end PCB manufacturing and PCB assembly services, delivering fully customized solutions from prototype to mass production.
What Is a Multilayer PCB?
A multilayer PCB (Printed Circuit Board) consists of three or more conductive copper layers laminated together with insulating materials.
Compared with single-layer or double-sided PCBs, multilayer boards offer:
-
Higher circuit density
-
Better signal integrity
-
Improved electrical and mechanical performance
They are widely used in industrial electronics, medical devices, telecommunications, automotive electronics, and high-speed systems.
Key Features of This 10-Layer PCB
-
10-layer stack-up for complex circuit routing
-
Minimum line width / spacing: 3mil / 3mil
-
Blue solder mask with clear surface finish
-
High-density layout suitable for precision electronics
-
Impedance-controlled design for high-speed signals
This PCB structure supports stable performance in demanding operating environments.
Advantages of Multilayer PCB Manufacturing
High Circuit Density
Multiple copper layers allow more functions in a smaller board size, ideal for compact electronic products.
Excellent Signal Integrity
Dedicated power and ground layers reduce EMI and ensure reliable signal transmission.
Strong Reliability
Multilayer construction improves mechanical strength and thermal stability for long-term use.
Optimized Thermal Performance
Advanced layer stack-ups help distribute heat evenly and improve system reliability.
Full Customization
Materials, copper thickness, surface finish, and layer count can be fully customized based on project requirements.
Technical Challenges & Our Solutions
Manufacturing high-quality multilayer PCBs requires strict process control, including:
-
Accurate layer alignment and lamination
-
Fine line etching for high-density designs
-
Controlled impedance for high-speed routing
-
Comprehensive inspection to prevent internal defects
With 17 years of PCB & PCBA experience, Ring PCB utilizes advanced equipment and mature processes to ensure stable quality in both prototyping and mass production.
| Parameter | Specification |
| Layer Count | 4 – 16 Layers |
| Min. Line Width / Spacing | 3mil / 3mil |
| Board Thickness | 0.8mm – 3.2mm |
| Copper Thickness | 1oz – 6oz |
| Surface Finish | ENIG, HASL, OSP, Immersion Silver |
| Solder Mask Color | Blue / Green / Black (Custom) |
| Material | FR-4, High-Tg FR-4, Rogers |
| Impedance Control | Supported |
| Applications | Industrial, Medical, Telecom, Automotive |
One-Stop PCB & PCBA Service
Ring PCB offers full turnkey PCB and PCB assembly services, including:
-
PCB fabrication
-
SMT & THT assembly
-
Component sourcing & BOM management
-
Functional testing & quality inspection
-
ODM / OEM / EMS solutions
This allows customers to focus on product development while we handle manufacturing efficiently.
Why Choose Ring PCB?
-
17 years of PCB & PCBA manufacturing experience
-
500+ skilled employees
-
5,000+㎡ self-owned factories in Shenzhen & Zhuhai
-
Certified with ISO9001, ISO14001, ISO13485, IATF16949
-
Fast turnaround: 3-day PCB prototype, 7-day mass production
-
Products exported to 50+ countries worldwide
-
Fully customized one-stop PCBA solutions
Applications
This 10-layer multilayer PCB is suitable for:
-
Industrial control systems
-
Medical electronic devices
-
Communication equipment
-
Automotive electronics
-
High-speed and high-reliability products
Contact Us
📧 Email: rfq@ringpcb.com
