RingPCB provides custom full turnkey radar PCBA for automotive, industrial and security sensors.
1.What are Radar PCBAs?
Radar systems are integral to various industries, including automotive, aerospace, defense, and telecommunications. Ring PCB, with its state-of-the-art Shenzhen factory, has been manufacturing radar PCBAs for a decade, delivering unparalleled quality and innovation.
2.Understanding Radar PCBA
Radar systems require high-performance PCBAs to handle the sophisticated processing of signals and electromagnetic waves. Radar PCBAs often include advanced features such as:
1. High-Frequency Performance: Radar systems operate at high frequencies (GHz range), necessitating PCBs with controlled impedance and low signal loss.
2. Durability: These systems often operate in harsh environments, requiring robust materials and designs to ensure reliability.
3. Complex Designs: Radar PCBAs incorporate multi-layer boards to accommodate high-density components and advanced functionalities.
3.Applications of Radar PCBA:
Ring PCB’s radar PCBAs are utilized in various sectors, including:
Automotive: For adaptive cruise control, collision detection, and parking assistance systems.
Aerospace: Supporting air traffic control and weather monitoring systems.
Defense: Enabling surveillance, target acquisition, and missile guidance.
Telecommunications: Enhancing network coverage through radar-based systems.
Stringent Quality Standards
Challenge:
Radar applications demand PCBAs that meet strict industry standards, such as ISO 9001, IPC-6012, and even military-grade certifications.
How Ring PCB Solves It:
1. Certified Facility: Our Shenzhen factory is compliant with global standards, ensuring reliable and high-quality production.
2. Comprehensive Testing: We conduct exhaustive testing, including:
- Functional Testing to validate performance.
- Automated Optical Inspection (AOI) for defect detection.
- In-Circuit Testing (ICT) to ensure electrical integrity.
3. Documentation and Traceability: Advanced tracking systems provide full traceability for every production batch.
5.Common technical parameters of Radar PCBAs
| Parameter | Description |
| Board Thickness | 0.8 – 2.0 mm (common values: 0.8 mm, 1.2 mm, 1.6 mm, 2.0 mm) |
| Number of Layers | 4 – 6 layers |
| Substrate Material | RO3003, Isola 370HR, etc. |
| Copper Thickness | 1 oz (about 35 μm), can be increased to 2 oz or more for high – current applications |
| Surface Treatment | Immersion silver, HASL (Hot – Air Solder Leveling), etc. |
| Board Color | Green, black, white, red, blue, etc. |
| Process | SMT (Surface Mount Technology), DIP (Dual In – line Package), etc. |
| Testing | Includes ICT (In – Circuit Test), FCT (Functional Circuit Test), AOI (Automated Optical Inspection), etc. |
| Frequency Band | 24 GHz, 60 GHz, 77 GHz, 79 GHz, etc. (automotive millimeter – wave radar commonly uses 77 GHz and 79 GHz) |
| Power | Varies by specific application and model, generally in the range of several watts to dozens of watts |
| Chip | Texas Instruments IWR1843BOOST, NXP and STMicroelectronics microcontrollers, etc. |
| Antenna Type | Microstrip array antenna, etc. |
ringPCB workshop
RingPCB SMT lines
✅ Why Choose Ring PCB?
-
18 Years of Expertise – Proven experience in multilayer PCB stack-up design and lamination
-
Fully Integrated Factory – PCB fabrication, SMT assembly, and testing under one roof
-
Strict Quality Control – 100% E-testing, AOI inspection, and functional testing
-
Flexible Order Options – From prototype to high-volume production with guaranteed consistency
-
Custom PCB Solutions – Based on customer-provided Gerber files, BOMs, and assembly drawings
-
Certified Manufacturer – UL, ISO9001, ISO14001, ISO13485, IATF16949
-
Compliance with international standards for safety, durability, and performance.
Whether you develop short-range millimeter-wave radar, long-distance industrial detection radar or vehicle-mounted safety radar modules, our full turnkey radar PCBA service removes the hassle of coordinating multiple suppliers. Submit your Gerber files, BOM list and radar performance requirements to us right away, and our engineering team will tailor a cost-effective, high-stability radar PCBA solution with a competitive quotation at once.
